| Display |
Interface: 1 HDMI, 1 VGA
Resolution:HDMI: 3840 × 2160 , 1920 × 1080 , 1280 × 1024,
1280 × 720 , 1024 × 768
VGA: 1920 × 1080 , 1280 × 1024,
1280 × 720 , 1024 × 768
Decoding Capability:4-ch@8MP(30fps), 16-ch@1080P(30fps)
Multi-screen Display:8CH: 1/4/8/9
16CH: 1/4/8/9/16:32CH: 1/4/8/9/16/25/36
OSD:Camera title, Time, Camera lock, Motion detection, Recording
|
| Network |
Interface: 1 RJ-45 Port (10/100/1000Mbps)
PoE: N/A
Network Function:HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, IP Search (Support IP camera, DVR, NVS, etc.), Easy4IP
Max. User Access: 128 users
Smart Phone: iPhone, iPad, Android
Interoperability:ONVIF 2.4, SDK, CGI
|
| Playback and Backup |
Sync Playback: 8CH: 1/4/9
16/32CH: 1/4/9/16
Search Mode:Time /Date, Alarm, MD and Exact Search (accurate to second)
Playback Function:Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom
Backup Mode: USB Device/Network
|
| Recording |
Compression:Smart H.265+/H.265/Smart H.264+/H.264/MJPEG
Resolution:12MP with 15fps, 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, 1.3MP, 720P, D1, CIF with 30fps
Bit Rate:16Kbps ~ 20Mbps Per Channel
Record Mode:Manual, Schedule (Regular, MD(Motion Detection) , Alarm, IVS), Stop
Record Interval:1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Storage |
Internal HDD:2 SATA III Ports, Up to 10 TB capacity for each HDD
eSATA:N/A
|
| System |
Main Processor:Quad-core embedded processor
Operating System: Embedded LINUX
|
| Video and Audio |
IP Camera Input:8/16/32 Channel
Two-way Talk: 1 Channel Input, 1 Channel Output, RCA
|
